Product Highlights

High durability manganese steel tank body, wear resistant, double spiral blades. Features: 8mm high-strength manganese steel drum. Double helix blades ensure a residual rate of less than 0.5% and no delamination phenomenon.

Powerful power system engine, heavy duty chassis, 6x4 drive. 380HP engine with reinforced chassis. Specially designed for harsh road conditions and heavy loads.

Precision hydraulic pump, motor, PLC control. Features: Original Eaton/Rexroth hydraulic system. Stable rotation, precise PLC control, fast unloading. Global support and service: 24/7 service, spare parts supply, customized painting. Features: Localized after-sales support, complete spare parts inventory. Customizable logos and colors.

product-1-1

Parameter Category	Parameter Item	Standard Configuration Details	Optional Customization
Vehicle General Parameters	Rated Mixing Volume	4m³ (Cubic Meters)	3m³ / 5m³ adjustable
	Overall Dimensions (L×W×H)	7092×2380×3450mm	Customizable based on local road dimension limits
	Total Vehicle Weight	7500kg	Reinforced chassis for 9000kg total weight
	Drive Type	4×2 (Two-Wheel Drive)	4×4 Four Wheel Drive for complex road conditions
	Steering Layout	Left-Hand Drive	Right Hand Drive for right-side traffic regions
Chassis System Parameters	Chassis Brand	Dongfeng Original Chassis	Shifeng / Wuzheng agricultural chassis for low cost options
	Wheelbase	3650mm	3300mm short wheelbase for ultra-narrow roads
	Suspension	Reinforced leaf spring suspension	Air suspension for smoother running
	Tire Specification	7.50R16 heavy-duty tires	8.25R16 reinforced off road tires
	Safety Configuration	Standard braking system, anti-slip pedal	ABS anti-lock system, backup camera, tire burst protection
Mixing Tank & Hydraulic System Parameters	Tank Material	6mm thick Q345 high manganese steel	8mm thick wear resistant steel for heavy-duty use
	Tank Head Thickness	8mm	10mm reinforced anti impact design
	Mixing Blade	High-strength wear-resistant alloy steel	Replaceable wear resistant blade strips
	Hydraulic System	Domestic mature brand reducer + hydraulic motor	Imported brand hydraulic system for higher stability
	Discharge Residue Rate	≤0.8%	Customized optimized fluid design for lower residue
Power System Parameters	Engine Brand	Yuchai 140HP diesel engine	Quanchai / Yunnei engine options
	Emission Standard	Euro III / National III	Euro II / Euro V to meet local environmental regulations
	Transmission	5-speed manual transmission	6-speed transmission for better climbing performance
	Cooling System	Independent hydraulic oil cooling system	Enhanced cooling system for high-temperature regions

product-1-1

Company Introduction

About Us

Sute Silk Road Automobile Trading Co., Ltd. is a truck manufacturer from Jining, Shandong, China. We have nearly 20 years of production history in this field of trucks, with direct sales from manufacturers, high quality, and the most favorable prices. Our products can be customized according to various needs. And unique company logos can be customized. The factory adopts advanced automation equipment. The steel welding adopts automatic submerged arc welding technology. Compared with traditional manual welding methods, the connection points are more perfect, flawless, and durable.We specialize in semi trailers and trucks, as well as second-hand trucks and semi trailers. We have our own semi trailer factory. We provide 24-hour service and one year after sales service. We prioritize integrity and establish long term partnerships with our customers. We look forward to working together with you!
