Low flatbed semi-trailer is commonly used for transporting heavy vehicles (such as tractors, buses, special vehicles, etc.), railway vehicles, mining machinery, forestry machinery, engineering machinery (such as excavators, bulldozers, loaders, pavers, cranes, etc.), and other heavy goods. The lower the center of gravity, the better the stability and safety, and the better able to transport ultra-high cargo and overcome overhead obstacles.
Product Specifications
| size(mm) |
9500-16500*2500-3000*3200(customizable)
|
| Tare(kg) |
8000-12800
|
| capacity(T) |
30-100
|
| main beam | Q690 steel |
| side beam | 16mm-25mm high-strength steel plate bending |
| platform | Pattern steel plate with a thickness of 3mm to 5mm |
| ladder climbing | hydraulic |
| axle | 5 axle |
| kingpin | Jost 2.0 or 3.5-inch bolt type |
| suspension system | Mechanical suspension/air suspension |
| leaf spring | 90mm (width) * 13mm (thickness) * 10 layers |
| braking system | WABCO No. 6 relay valve, spring brake chamber, 2 45 liter air storage tanks |
| tire |
12.00R22.5
|
| painting | One layer of anti corrosion treatment for primer and two layers of topcoat, with the color specified by the customer. |
This series of low flatbed semi-trailer has a flat plate, concave beam, and exposed tire structure. The framework is stepped,
The longitudinal beam has an I-shaped cross-section and is characterized by high stiffness and strength.
The main plane of the frame and cargo platform is relatively low, ensuring transportation stability and suitable for transporting various construction machinery, large equipment, and steel.
Open design: No fixed side walls or ceiling, convenient for loading and unloading in all directions, especially suitable for lifting and forklift loading and unloading.
Spacious flatbed carriage: The flatbed carriage design provides a larger loading area, making it easy to carry oversized, oversized, and irregularly shaped cargo.
Sturdy structure: Made of high-strength steel, it has excellent load-bearing capacity and durability, suitable for heavy cargo transportation.
Uniform distribution: The weight can be evenly distributed across the entire tablet, reducing single point pressure and improving safety.
