Skeleton semi trailer, also known as container chassis, container trailer or skeleton trailer, is a type of semi trailer specifically designed for transporting various sizes of shipping containers (mainly 20 foot, 40 foot, sometimes 45 foot containers). It consists of a sturdy open frame or "skeleton" structure with a locking mechanism (twist lock) to secure the container during transportation. Unlike flatbed trailers with continuous decks, skeleton trailers have the smallest surface area, exceeding the necessary support and locking points for containers. This design minimizes weight and maximizes payload capacity.
2 axis 3 axis 20ft 40ft skeleton gooseneck container chassis trailerWhen using a container chassis trailer to transfer goods, they can be directly loaded in the shipper's warehouse and transported to the consignee's warehouse for unloading. When changing vehicles and ships midway, there is no need to remove the goods from the container and reload them.It can be quickly loaded and unloaded, and can be easily converted from one mode of transportation to another.
Due to its simpler design and lower weight, skeleton trailers typically have lower purchasing and operating costs compared to other types of trailers. They also require less maintenance.
| Chinese Description | English Specification |
|---|---|
| Product Name | Container Skeleton Semi-Trailer |
| Available Models | 20ft Skeleton Semi Trailer40ft Skeleton Semi-Trailer45ft Skeleton Semi Trailer |
| Axle Options | 2 Axles / 3 Axles3 Axles / 4 Axles3 Axles / 4 Axles |
| Container Loading Mode | For 20ft ContainerCarry 1×40ft or 2×20ft ContainersCarry 1×45ft / 1×40ft / 2×20ft Containers |
| Loading Capacity | 20–50 Tons30 80 TonsLoading Capacity: 30 80 Tons |
| Trailer Frame Type | Type: Gooseneck or TandemType: Gooseneck or Tandem |
| Main Beam Material | Material: Q345 / T700Material: T700 |
| Upper Beam Plate Thickness | Upper Plate Thickness: 12mmUpper Plate Thickness: 14mmUpper Plate Thickness: 10mm |
| Middle Beam Plate Thickness | Middle Plate Thickness: 6mmMiddle Plate Thickness: 5mm |
| Bottom Beam Plate Thickness | Bottom Plate Thickness: 12mmBottom Plate Thickness: 16mmBottom Plate Thickness: 10mm |
| Trailer Frame Height | Height: 500mmHeight: 420mm |
| Overall Dimension (L×W×H) | 7000mm × 2480mm × 1560mm12400mm × 2480mm × 1580mm13950mm × 2500mm × 1600mm |
| Axle Configuration & Brand | 2/3 Axles × 13T, Brands: Vehicle Master / Fuwa / BPW or Equivalents3/4 Axles × 13T, Brands: Vehicle Master / Fuwa / BPW or Equivalents3/4 Axles × 13/16T, Brands: Vehicle Master / Fuwa / BPW or Equivalents |
| Tire Spec & Brand | 12R22.5 (8/12 Pcs), Brands: Linglong / Triangle / Double Coin / Bridgestone12R22.5 (12/16 Pcs), Brands: Linglong / Triangle / Double Coin / Bridgestone |
| Rim Spec & Material | 9.00×22.5 (8/12 Pcs), Material: Steel / Aluminum Alloy9.00×22.5 (12/16 Pcs), Material: Steel / Aluminum Alloy |
| Leaf Spring Spec | 90mm×13mm×10 Pcs90mm×16mm×10 Pcs |
| King Pin | King Pin: #50 (2") / #90 (3.5"), Brands: JOST or Equivalents |
| Landing Gear | Landing Gear: 28 Tons Two Speed, Brands: JOST or Equivalents |
| Twist Lock Quantity | 4 Sets12 Sets |
Packaging and delivery
Shipping Deadline
Container: The cheapest and fastest container; Placing the machine into a container requires disassembly.
Flat frame: commonly used for loading two wheeled loaders, with a maximum load capacity of 35 tons.
Bulk carrier: Which better construction equipment is larger and does not require dismantling.
Roll on/roll off ship: The machine is directly inserted into the ship without dismantling.
Sute Silk Road Automobile Trading Co., Ltd. is a truck manufacturer from Jining, Shandong, China. We have nearly 20 years of production history in this field of trucks, with direct sales from manufacturers, high quality, and the most favorable prices. Our products can be customized according to various needs. And unique company logos can be customized. The factory adopts advanced automation equipment. The steel welding adopts automatic submerged arc welding technology. Compared with traditional manual welding methods, the connection points are more perfect, flawless, and durable.We specialize in semi trailers and trucks, as well as second hand trucks and semi trailers. We have our own semi trailer factory. We provide 24 hour service and one year after sales service. We prioritize integrity and establish long term partnerships with our customers. We look forward to working together with you!
Our address
QuanPu Industrial Park, Liangshan, Jining, Shandong
Phone Number
+8615265769333
15166736520@163.com
QC Process
FAQ
Q: Can this trailer carry anything other than 20ft containers?
A: It's purpose-built for 20ft ISO containers, but many skeleton trailers can also handle 40ft or even two 20ft containers in tandem with the right configuration.
Q: How do I secure the container?
A: Four twist locks at the corners lock into the container's corner castings. Just engage them until you hear a click – that's your signal it's secure.
