Product Showcase
A car transport vehicle refers to a vehicle used for transporting automobiles.
The car trailer can be made into different lengths according to customer requirements, with a welded I beam frame and the entire body using automatic submerged arc welding and carbon dioxide gas shielded welding.
Skeleton type, where the side panels are composed of columns, excluding side panels, front panels, rear doors, and top panels. This type of car carrier is lightweight, low cost, and has low fuel consumption, but it is inconvenient to transport goods and the car is prone to damage.
The structure of a car bracket is generally divided into lower chassis, upper chassis, side panels, front panel, rear door, top panel, accessories, hydraulic system, suspension system, air brake system, circuit system, support device, a wheel hub cooling system, etc.
The car bracket is a double layer loading platform structure. The upper loading platform can be lifted up and down by a lifting device for easy loading. The lifting device can be configured according to different needs and can be divided into three types: hydraulic cylinder direct lifting, pulley wire rope traction lifting, and manual winch suspension.
For dual axle twin tire transport vehicles, there are two manual springboards on the goose neck steps at the front end of the lower chassis, a movable frame that can be lifted by a hydraulic cylinder is designed in front of the rear axle, two manual springboards on the left and right sides are designed behind the rear axle, and drawers and ladders are designed at the rear end. A drawer has been designed at the back of the upper chassis.
Product Specifications
| Vehicle specifications | Specification of longitudinal beam | ||
| Size | Height | 350mm Q355NELow high-temperature resistant material | |
| Length | Upper wing plate |
Upper wing plate |
10MM |
| Width | Lower wing plate |
Lower wing plate |
10MM |
|
Height |
Belvet plank |
Plate |
6MM |
| Vehicle configuration specifications | |||
| Tyre |
12.00R22.5 |
Kingpin |
50#/90 # kingpin |
| Baseplate | Punching plate 2.75 # (material 235) | Supporting leg | Simple leg support |
| Screw | 8 pieces | Synchronous valve |
WABCO |
| Toolbox | 2 pieces | Airbag |
BPW |
| Spare tire rack | 2 pieces | Axle | 2 axis |
| Light | Light emitting diode lamp | Suspension system | Mechanical suspension/air suspension |
| Power supply |
24V |
Braking system | BPW T30/30 dual chamber 4 pieces |
|
Rated load capacity: 20T |
|||
| 1. Second level lifting method: Spiral lifting 2. Includes a power unit, motor: domestically produced 5500 watts 3. Overall hot-dip galvanizing process for vehicles |
|||
Production Workshop
Use case and customer feedback diagram
Transportation and Delivery
Partners
Supplier Introduction
Our trucks are sold to Africa, Central Asia, South Africa, Nigeria, Tanzania, Ghana, Kenya, Zambia, Algeria, Congo, Uganda, Gambia, Mali, Pakistan, Ethiopia, Togo, Zimbabwe, Jamaica, Rwanda, Angola, Nepal, Benin, Libya, Asia, Burundi, Gabon, Namibia and other countries.
FAQ
Can I customize various models of transportation vehicles?
A: Yes. We have the most advanced modern production equipment and manufacturing processes. We can make products according to your special requirements.
Q: Can I get more photos or videos
A: Yes, we can provide authentic photos and videos for your reference
Q: May I visit your factory?
A: Of course, our factory is located in Jining, Shandong, China. You are welcome to visit our factory!
Q: What is your term of payment?
A: 30% down payment before producing and 70% balance payment before shipping.
Q: What is the delivery time for bulk orders?
A: This depends on the number of orders. Usually, the delivery time is 7-25 days. Please contact us before placing an order.
Q: Do you support overseas transportation
A: Yes, we have extensive export experience and can arrange global shipments
